Operation Breakdown, SMV and Layout of Shimmer Dress

Shimmer dress specially made for girls which are used on different occasions around the world by the models or celebrities. The shimmer gives a girl a gorgeous look.

Contents hide

Machine Summary of Shimmer Dress

Operation Breakdown, SMV and Layout of Shimmer Dress

The dress is come up with different colors with a shiny outlook. Here in this article, you will have operation breakdown, SMV, and layout of shimmer dress manufacturing. Total Manpower Requirement = 27 Person for garments production, Total Machine Requirement is 27 and Total SMV of shimmer dress manufacturing is 17.60.

SQ NO	OPERATION DESCRIPTION	M/C TYPE	SMV	TML	AML
1	Msr & cut tape to length & tape thru zip & l/s secure	SNLS	0.442	0.68	1.0
2	Attach tape to lower edge of inner collar	SNLS	0.667	1.02	1.0
3	Join inner & outer collar at outer edges	4TH/OL	0.667	1.02	1.0
4	Bluffstitch inner & outer collar	SNLS	0.683	1.05	1.0
5	Shoulders with / without tape	4TH/OL	0.625	0.96	1.0
6	Insert sleeves	4TH/OL	0.920	1.41	1.5
7	Mark & attach outer collar onto neck edges	4TH/OL	0.750	1.15	1.0
8	Mark & l/s attach frt pkt linner to frt pnl at pkt opening	SNLS	0.667	1.02	2.0
9	Snip, turn & l/s topstitch front pocket openings to form welt effect	SNLS	0.850	1.30	1.0
10	Close frt linner to bk pkt bags	4TH/OL	0.500	0.77	1.5
11	Secure tack pkt bags into pos at sideseams	SNLS	0.720	1.10	2.0
12	Sides/sleeves long wrap inc labels	4TH/OL	1.500	2.30	2.0
13	Hem wrap	2FL/L-C	0.917	1.41	1.0
14	Mark & l/s attach zip to CF inside	SNLS	2.500	3.84	2.0
15	Bagout inner collar at CF neck on zipper edge	SNLS	0.500	0.77	2.0
16	Neaten Centre body from collar edge to hem edge	4TH/OL	1.167	1.79	1.0
17	Topstitch zip into pos	SNLS	0.660	1.01	1.0
18	Close inner collar tape seam with loop	SNLS	0.750	1.15	2.0
19	Cuffs (circular) long slv dress	2FL/ SCB	0.819	1.26	1.0
20	iron fleece/toweling/ knitted long wrap	–	1.167	1.79	1.0
21	Form back neck loop, msr & cut to length	2FL/ CB	0.129	0.20	–
–	Total	–	17.60	27.0	27

Machine Summary of Shimmer Dress

Machine Type	Short Code	Required QTY
Single Needle Lock Stitch	SNLS	15
4 Thread Over Lock	4TH/OL	9
2 Needle Flat Lock Cover Seam Small Cylinder Bed	2FL/SCB	1
2 Needle Flat Lock Cover Seam Cylinder Bed	2FL/CB	1
2 Needle Flat Lock Cover Seam Left Side Cutter	2FL/L-C	1
Total	–	27
