In this article, you will have details of Operation Breakdown, SMV and Layout of Ladies Overall

  • Allocated ManPower = 77 Person
  • Total SMV = 32.93
  • Number of Machine = 53 Unit
SEQ NOOPERATIONM/C
Types
SMVMP
1Front pocket position markMNL0.441
2Pocket edges hem2FL/ SCY0.321
3Pre iron pocket edgesIRON0.701
4Pocket attachSNLS1.202
5Pocket extra raw edges cutMNL0.501
6Back pocket & flap position markMNL0.521
7Fusing attach at pocket edgeIRON0.201
8Pocket edges hem2FL/ SCY0.301
9Pocket pressIRON0.701
10Pocket attach at back partSNLS1.202
11Pocket extra raw edges cutMNL0.501
12Fusing attach at flapIRON0.241
13Flap makeSNLS0.801
14Pocket flap edge cut & turn with pressIRON0.401
15Flap 1/16 topstitchSNLS0.801
16Flap 1/4 topstitchSNLS0.751
17Flap attach n topstitchSNLS0.882
18Rise join keeping front rise upto cutmark open4TH/OL0.651
19Front rise upper tackSNLS0.181
20Front & back part matchMNL0.281
21Side markMNL0.301
22Care label makeSNLS0.241
23Side seam join inserting care label4TH/OL0.801
24Sleeve mark for tape attachMNL0.441
25Sleeve tape attach & cutFOA0.882
26Sleeve & body sticker matchMNL0.351
27Insert raglan sleeve to body4TH/OL1.102
28Body mark to cutMNL0.181
29Body cutMNL0.201
30Collar fold & edge tackSNLS0.281
31Collar edge close & markSNCS0.301
32Collar tack to bodySNLS0.281
33Collar attach to body4TH/OL0.301
34Neck topstitch1FL/ CY0.421
35Zipper runner secure tack & zipper edge fold tackSNLS0.401
36Zipper edge binding & cut1FL/BIN0.561
37Binding edges tack & cutSNLS0.321
38Side seam join4TH/OL0.421
39Mark & make holeB/H0.361
40Tie cut to lengthMNL0.201
41Tie edge fold & tackSNLS0.361
42Tie edge secure to holeSNLS0.401
43Elastic press & cut to length *3IRON0.361
44Elastic sandwich tackSNLS0.401
45Elastic attach at both side of waist tunnel3TH O/L0.601
46Top & bottom part matchMNL0.281
47Tunnel part attach4TH/OL0.902
48Zipper n body markMNL0.351
49Mark & fistail cutMNL0.301
50Zipper tackSNLS0.281
51Zipper attachSNLS1.002
52Zipper base neaten4TH/OL0.161
53Zipper base secureSNLS0.181
54Elastic join as a circleDNLS0.301
55Cuff join as a circleSNLS0.301
56Elastic attach to cuff3TH O/L0.401
57Cuff fold & tackSNLS0.401
58Cuff edge close & markSNCS0.451
59Cuff attach at leg4TH/OL0.501
60Sticker remove & gmt turnMNL0.351
61Sleeve edge neaten3TH O/L0.421
62Sleeve hem1FL/ CY0.501
63Zipper topstitchSNLS1.102
64Label position markMNL0.161
65Label attachSNLS0.301
66Button position markMNL0.441
67Button attach to pocket & flapB/A1.202
68Thread trim, Zipper & button closeMNL0.651
Total32.9377
Operation Breakdown, SMV and Layout of Ladies Overall

Machine Summary of Ladies Overall

CodeMachine nameQuantity
SNLSSingle Needle Lock Stitch27
SNCSSingle Needle Chain Stitch2
DNLSDouble Needle Lock Stitch1
3TH O/L3 Thread Over Lock3
4TH/OL4 Thread Over Lock10
2FL/ SCY2 Needle Flat lock Small  Cylinder Bed2
1FL/ CY1 Needle Flat lock Cylinder Bed2
1FL/BIN1 Needle Flat lock Binding Machine1
B/AButton Attach2
B/HButton Hole1
FOAFeed Of The Arm2
Total No of Machines53

Manpower Summary of Ladies Overall

MNLManual (Helper)18
IRONIron With Table6
Total No of Manpower77
